12 Fibers MPO To LC Singlemode Fiber Optic MPO-LC 2.0mm Straight Harness Cables

Product Name

12F MPO SM Fiber Optic MPO-LC 2.0mm Straight Harness Cables

Product Description

The 12F MPO Single-Mode Fiber Optic MPO-LC 2.0mm Straight Harness Cable is a robust, high-performance

fiber optic solution designed to streamline cable management and ensure superior connectivity in high-density environments.

Featuring a 12-fiber MPO to 6 LC Duplex (6xLC uniboot) or 12 LC Simplex fanout design, this cable is optimized for

applications such as 40G QSFP+ PLR4 to 10G SFP+ LR optics direct connections and other high-speed data center use cases.

This harness cable is especially suited for:

• Data center environments demanding efficient space utilization and reduced cable clutter.
• Fiber-to-the-building (FTTB) solutions.
• High-performance internal fiber equipment interconnections for devices like QSFP+ and SFP+.

Key Features

• Low Insertion Loss and High Return Loss: Ensures efficient data transmission and signal integrity.
• Plug-and-Play Design: Pre-terminated for rapid deployment.
• High-Density Design: Reduces cable bulk, optimizes airflow, and saves valuable rack space.
• Color-Coded Housings: Simplifies identification of fiber and polish types.
• Durability and Reliability: Engineered for 200 matings with minimal loss changes.
• Wide Compatibility: Supports single-mode and multimode applications across multiple standards.

Connector Details

MPO Connector (Single-Mode APC)

• Standard Loss: ≤0.75dB (max), ≤0.50dB (typical)
• Super Low Loss: ≤0.35dB (max), ≤0.20dB (typical)
• Return Loss: ≥60dB (8-degree polishing)

LC/SC/FC/ST Connectors

• Insertion Loss: ≤0.3dB
• Return Loss:
  • APC: ≥60dB
  • UPC: ≥50dB

Industrial Compliance

• MPO Connectors: IEC 61754-7 standard
• LC/SC/FC/ST Connectors: IEC61754 series, GR-326, TIA/EIA compliance
• Meets Standards: IEC-61754-7, Telcordia GR-1435-CORE, TIA-604-5 (FOCIS5), TIA-568-C
• Supported Applications: IEEE 802.3 for 10G, 40G, and 100G Ethernet

Optical Specifications

• Insertion Loss (MPO):
  • Standard Loss: ≤0.75dB (max), ≤0.50dB (typical)
  • Super Low Loss: ≤0.35dB (max), ≤0.20dB (typical)
• Insertion Loss (LC/SC/FC/ST): ≤0.3dB
• Return Loss (MPO): ≥60dB for single-mode
• Durability: ≤0.3dB typical change over 200 matings
• Tensile Strength: >70N

Applications

• 40G LR4 PSM, 40GBASE-SR4, and 40G QSFP+ PLR4 interconnections.
• 10G/40G/100G high-density data center connections.
• Fiber-to-the-building (FTTB) for internal and external network connections.
• Direct QSFP+ to SFP+ connectivity without the need for intermediate patch panels.

Available Fiber Types

• Single-Mode: G657A1, G657A2/B2, G657B3
• Multimode: OM1, OM2, OM3, OM4, OM5

Advantages

• High Quality: Factory pre-terminated, tested, and shipped with certified test reports.
• Space Efficiency: Compact cable design minimizes cable volume, improving airflow in dense environments.
• Time-Saving Deployment: Plug-and-play setup reduces installation time and complexity.
• Reliable and Repeatable Performance: Designed for long-term use with consistent results.

• 7236037 | ZCM11A12HIAX: 8F MPO SM Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
The 8F MPO Single-Mode Fiber Optic MPO-LC 2.0mm Straight Harness Cable ensures efficient and reliable high-density

connections. Designed for data centers and enterprise networks, this harness cable features an 8-fiber MPO connector at one

end and LC connectors at the other, offering low insertion loss and high return loss for 40G/100G Ethernet.

• 7236038 | ZCM11A22HIAX: 12F MPO SM Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
The 12F MPO Single-Mode Fiber Optic MPO-LC 2.0mm Straight Harness Cable provides seamless connectivity for high-speed

networks. With its 12-fiber MPO and LC connectors, this harness cable supports 10G/40G/100G Ethernet and is optimized for low-loss

performance in dense environments.

• 7236039 | ZCM11A52HIAX: 24F MPO SM Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
This 24F MPO Single-Mode Fiber Optic MPO-LC Harness Cable supports 40G/100G Ethernet in high-density environments.

Its robust design, featuring a 2.0mm jacket and superior optical performance, ensures efficient data transmission with low insertion loss.

• 7236040 | ZCM11A17HAAX: 8F MPO OM3 Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
The 8F MPO OM3 Fiber Optic MPO-LC 2.0mm Straight Harness Cable is perfect for high-speed multimode (OM3) connections

in data centers. Its 8-fiber MPO connector and LC connectors ensure reliable performance for 10G/40G Ethernet applications.

• 7236041 | ZCM11A27HAAX: 12F MPO OM3 Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
The 12F MPO OM3 Fiber Optic MPO-LC Harness Cable delivers exceptional performance for 10G/40G Ethernet connections.

With its OM3 multimode fiber and durable 2.0mm jacket, it is a reliable solution for modern network infrastructures.

• 7236042 | ZCM11A57HAAX: 24F MPO OM3 Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
Engineered for high-density multimode networks, the 24F MPO OM3 Fiber Optic MPO-LC Harness Cable ensures superior

performance for data centers and backbone connections. It supports 40G/100G Ethernet with low loss and high reliability.

• 7236043 | ZCM11A18HMAX: 8F MPO OM4 Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
The 8F MPO OM4 Fiber Optic MPO-LC Harness Cable offers high-speed multimode (OM4) connectivity with superior optical

performance. Perfect for 40G/100G Ethernet, its compact 2.0mm jacket is ideal for dense network installations.

• 7236044 | ZCM11A28HMAX: 12F MPO OM4 Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
The 12F MPO OM4 Fiber Optic MPO-LC Harness Cable supports 10G/40G/100G Ethernet applications with excellent signal

integrity. Its OM4 multimode fiber and 2.0mm jacket ensure durability and reliability in demanding environments.

• 7236045 | ZCM11A58HMAX: 24F MPO OM4 Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
The 24F MPO OM4 Fiber Optic MPO-LC Harness Cable is designed for high-speed data center applications. Supporting multimode

OM4 fiber, it offers low-loss connectivity and superior performance for 40G/100G Ethernet.

• 7236046 | ZCM21A12HIAX: 8F MTP SM Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
The 8F MTP Single-Mode Fiber Optic MPO-LC Harness Cable is ideal for high-speed network connections. Its 8-fiber MTP

connector ensures low insertion loss, while the LC connectors provide seamless compatibility for 40G/100G Ethernet.

• 7236047 | ZCM21A22HIAX: 12F MTP SM Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
This 12F MTP Single-Mode Fiber Optic MPO-LC Harness Cable is perfect for high-density single-mode networks. With its durable

2.0mm jacket and reliable MTP-LC connection, it supports 10G/40G/100G Ethernet applications.

• 7236048 | ZCM21A52HIAX: 24F MTP SM Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
The 24F MTP Single-Mode Fiber Optic MPO-LC Harness Cable is designed for robust performance in high-speed networks.

Supporting 40G/100G Ethernet, its compact design is optimized for dense cabling environments.

• 7236049 | ZCM21A17HAAX: 8F MTP OM3 Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
This 8F MTP OM3 Fiber Optic MPO-LC Harness Cable provides reliable multimode (OM3) connectivity for data centers and

backbone networks. It supports 10G/40G Ethernet with minimal signal loss.

• 7236050 | ZCM21A27HAAX: 12F MTP OM3 Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
The 12F MTP OM3 Fiber Optic MPO-LC Harness Cable offers high-density multimode connectivity for modern data center

networks. It ensures low loss and reliable performance for 40G/100G Ethernet.

• 7236051 | ZCM21A57HAAX: 24F MTP OM3 Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
This 24F MTP OM3 Fiber Optic MPO-LC Harness Cable delivers outstanding performance for multimode connections. Supporting

high-speed 40G/100G Ethernet, it is ideal for dense network installations.

• 7236052 | ZCM21A18HMAX: 8F MTP OM4 Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
The 8F MTP OM4 Fiber Optic MPO-LC Harness Cable supports 40G/100G Ethernet with superior multimode (OM4) performance.

Its rugged 2.0mm jacket ensures reliability in high-density environments.

• 7236053 | ZCM21A28HMAX: 12F MTP OM4 Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
The 12F MTP OM4 Fiber Optic MPO-LC Harness Cable offers low-loss performance for high-speed multimode networks.

It is optimized for 10G/40G/100G Ethernet in modern data centers.

• 7236054 | ZCM21A58HMAX: 24F MTP OM4 Fiber Optic MPO-LC 2.0mm Straight Harness Cable

Description:
The 24F MTP OM4 Fiber Optic MPO-LC Harness Cable is engineered for high-speed, high-density multimode (OM4) networks.

Supporting 40G/100G Ethernet, it delivers exceptional performance and reliability.
