| Place of Origin: | China |
|---|---|
| Brand Name: | Zion communication OR OEM |
| Certification: | CE, RoHS, VDE, UL |
| Model Number: | Industrial CAT5e Cable |
| Minimum Order Quantity: | 10 KM |
| Packaging Details: | 500FT/PULL BOX, 1000FT/Wooden Spool,Pallet |
| Delivery Time: | 25 working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1000KM / Month |
| Conductor: | Stranded Copper Wire | Insulation: | Foam PE |
|---|---|---|---|
| Drain Wire: | Tinned Copper Wire | Shield: | AL Foil Wrapping And Copper Wire Braid |
| Jacket: | See Attached List | Color: | Black Or Other Colors |
| Highlight: | automation cables,high flex industrial ethernet cable |
||
https://www.zion-communication.com/Industrial-Ethernet-Cable-pl569518.html
| RS-485 | ||||||||
 |
||||||||
| ▉ Application | ||||||||
| Comply toRS-485 communication protocol, apply to complicated the controlled network of industrial automation and self-control network communication of building. Different cable design can be used in different applications. |
||||||||
| ▉ Cable Construction | ||||||||
| Conductor: Stranded copper wire | ||||||||
| Insulation: Foam PE | ||||||||
| Drain wire: Tinned copper wire | ||||||||
| Shield: AL foil wrapping and copper wire braid | ||||||||
| Jacket: see attached list | ||||||||
| Color: Color: Black or other colors | ||||||||
| ▉ Product Feature | ||||||||
| Oil and grease resistance | ||||||||
| Torsion resistance, Easy bending | ||||||||
| Fire resistance meets IEC60332-1 | ||||||||
| AL/Mylar and copper wire braid, excellent Anti-EMI performance | ||||||||
| UV and Abrasion resistance, Anti-hydrolysis | ||||||||
| ▉ Cross Section | ||||||||
 |
||||||||
| ▉ Technical data | ||||||||
| Temperature range | .-40℃ to 80℃ | |||||||
| Test voltage | 1500V 1min, no breakdown | |||||||
| Peak voltage | 250V | |||||||
| Characteristic impedance 100±15 Ohm | 120±15 Ohm | |||||||
| Min bending radius | Fixed installation:8x cable diameter | |||||||
| Moved installation:15x cable diameter | ||||||||
| Conductor DC resistance | 0.22mm²≤186 ohms/km | |||||||
| 0.25mm²≤159.8 ohm/km | ||||||||
| ▉ Product List | ||||||||
| Item No. | Spec. | Jacket | Nominal OD(mm) |
Copper.weight approx (kg/km) | Weight approx(kg/km) | |||
| 7130300 | 4*2*AWG26/7 | PVC | 6.4 | 25 | 49 | |||
| 7130301 | 4*2*AWG26/7 | PUR | 6.4 | 25 | 47 | |||
| 7130302 | 4*2*AWG24/7 | PVC | 7.8 | 40 | 74 | |||
| 7130303 | 4*2*AWG24/7 | PUR | 7.8 | 40 | 72 | |||
| ▉ Order Information | ||||||||
| Marking | HELLOSIGNAL Industrial RS-485 Cable XXXFT/M | |||||||
| Package | 500FT/PULL BOX, 1000FT/Wooden Spool,Pallet … | |||||||
| Delivery time | Normally 25 days after received the deposit. | |||||||
